Luster LusterTagTank-200
Technical specifications:
Application – For printed card, paper tag, and small size sheet & carton detection, covers cosmetic package, beer and liquid labels, garment tag, commercial tag & sheet etc.
Max. Inspection Size (L×W) – 200×200mm
Min. Inspection Size (L×W) – 30×50mm
Max. Speed – 280m/min
Paper weight – 90-350g/m²
Minimum defect size(as a pot) – 0.3mm²
Minimum defect size(as a line) – Width ≥ 0.1mm, Length ≥ 4mm
Mis-Registration inspection accuracy – 0.1mm
Color Deviation accuracy – ΔE ≥ 3
Max. Inspection Size (L×W) – 200×200mm
Min. Inspection Size (L×W) – 30×50mm
Max. Speed – 280m/min
Paper weight – 90-350g/m²
Minimum defect size(as a pot) – 0.3mm²
Minimum defect size(as a line) – Width ≥ 0.1mm, Length ≥ 4mm
Mis-Registration inspection accuracy – 0.1mm
Color Deviation accuracy – ΔE ≥ 3
Vision Inspection Solution
Front side inspection – 2D inspecting system: 4K resolution color RGB line-scan camera / Printing & Foil stamping inspection. 3D inspecting system: 4K resolution black & white line-scan camera / Embossing, lamination & varnishing inspection.
Back side inspection – 2D inspecting system: 4K resolution color RGB line-scan camera / Printing & Foil stamping inspection. 3D inspecting system: 4K resolution black & white line-scan camera / Embossing, lamination & varnishing inspection.
Other Workstation – Bar code, variable data inspection / RFID reading station (Optional).
Software – Inspection software PrintingPlus International Edition
Back side inspection – 2D inspecting system: 4K resolution color RGB line-scan camera / Printing & Foil stamping inspection. 3D inspecting system: 4K resolution black & white line-scan camera / Embossing, lamination & varnishing inspection.
Other Workstation – Bar code, variable data inspection / RFID reading station (Optional).
Software – Inspection software PrintingPlus International Edition
Platform Solution
Feeder Unit – Friction feeder
Conveying Unit – Mechanical platform + belt convey
Ejecting System – Air-blow ejection system with single stream waste collection exit, for printing defect ejecting
Collecting Unit – Fish-scale single stream collection
Machine Dimensions (L×W×H) – 5400×1100×1600mm
Machine weight – About 4.5T
Power supply – AC380V 15KW 50Hz Three-phase-five-wire
Compressed Air Supply – 0.8-1MPa
Conveying Unit – Mechanical platform + belt convey
Ejecting System – Air-blow ejection system with single stream waste collection exit, for printing defect ejecting
Collecting Unit – Fish-scale single stream collection
Machine Dimensions (L×W×H) – 5400×1100×1600mm
Machine weight – About 4.5T
Power supply – AC380V 15KW 50Hz Three-phase-five-wire
Compressed Air Supply – 0.8-1MPa
Description
TAG QUALITY INSPECTION EQUIPMENT
LUSTER TAGTANK-200
TagTANK-200 Tag Quality Inspection System is developed for quality inspection and final check of clothing tag, card and other small size sheet-fed products. It supports accurate inspection for front and back side printing with vacuum structure from both sides. It can achieve effective inspection of all kinds of defects as well as variable data and RFID inspection.
ABOUT LUSTER TAGTANK-200
MAIN FEATURES
– Optional RFID inspection and reading function.
– High accuracy double side inspection for print, graphics, text, code, lamination, coating etc..
– Feeder designed for small width of tags.
– One master image as reference, easy and quick to use.
– High speed and stable platform ensure high inspection precision.
– High accuracy double side inspection for print, graphics, text, code, lamination, coating etc..
– Feeder designed for small width of tags.
– One master image as reference, easy and quick to use.
– High speed and stable platform ensure high inspection precision.
